Two-wire 4-20mA Passive Loop Powered IC Model NO: JSD MI 4~20mA-F Size: 32X14.2X8.9mm

Isolation amplifier features:
Low cost, small size, SIP12 package with UL94-V0 flame retardant standard
Isolation voltage up to 3000VDC between Signal input and signal output
Provide work without external power supply, no external components
4 ~ 20mA current input, 4 ~ 20mA current output
Industrial temperature range: -45 ~ +85 Celsius
Accuracy class: 0.3, 0.4, 0.5;
High Linearity: 0.1% F. S.
Supplies power to the sensor (10 ~ 30VDC)

Two-wire 4-20mA Passive Loop Powered IC applications:
Analog signal data isolation, collecting
Industrial field signal isolation
Remote lossless transmission
Analog signal ground interference suppression
4 ~ 20mA isolated signal transmission
To the front two -wire equipment provide power supply
Instrumentation and sensor signal transceive
Power monitoring, medical equipment isolation barrier

Two-wires 4-20mA passive isolation amplifier IC general description:
JSD MI 4 ~ 20mA-F series isolation amplifier IC is a two-wire loop powered galvanic isolation module, the isolation module IC using electromagnetic isolation technology, To the two-wire devices powered, effective solution to the current signal isolation depends on the power supply and achieve the 4 ~ 20mA standard signal isolation and transmission, Can be used with a variety of instruments analog input interface (PLC, DCS systems, etc. ) match. Analog signal input with overcurrent protection, Can effectively protect the module and the post-stage circuit; Addition, the module's input and output isolation voltages up to 3000VDC.
JSD MI 4 ~ 20mA-F series isolation amplifier products very easy to use, without any external components, can achieve the industrial field signal isolation and conversion functions, and can achieve long-term lossless signal transmission. The product simplifies the user's design, greatly improves the PCB board space utilization.
